คำตอบที่ 6
ขอเอาข้อมูลใน web ลงให้ก่อนนะครับ แต่ถ้าต้องการรูปรายละเอียดอื่นๆวันหลังจะ scan ในหนังสื่อที่มีอยู่ให้ครับ
CJ-7 (1976-1986)
--------------------------------------------------------------------------------
Description
Built from late 1976-1986
Round fenders
93.5" wheelbase
55" wide windshield frame with bottom mounted wipers
rear mounted spare tire
factory roll bar
U door openning
5"x5.5" bolt pattern on wheels
81" from from door hinge to rear
ENgines
amc 232 cu in i-6 (standard from 1971-1979)
amc 258 cu in i-6
amc 304 cu in v-8 (last year 1981)
gm 151 cu in i-4 (1980-1983)
amc 150 cu in i-4 (1984-1986)
Transmissions
t-150 3 speed manual (i-6 1976-1979)*
t-18A 4 speed manual (i-6 1976-1986)*
t-176 4 speed manual (i-6, v-8 1980-1983)
sr-4 4 speed manual (i-4 1980-1981)
t-4 4 speed manual (i-4 1982-1983)
t-5 5 speed manual (i-4, i-6 1982-1983)
Chrysler 904 automatic (i-4 1981-1986)
chrysler 999 automatic (i-6, v-8 1980-1986)
GM TH-400 (v-8 1976-1979)
*known for being very stong
Transfer Cases
Dana 20 2-speed transfer case (1976-1979)
dana 300 2-speed transfer case (1980-1986)
BW1339 2-speed full time 4wd transfer case (AKA quadratrac)
rear Axle
amc 20 (1976-1983)
Dana 44 (some in 1986)
front axle
dana 30 (1976-1986)
For more detail and information check out The illustrated jeep buyers guide by Jim allen
--------------------------------------------------------------------------------
